High Brightness TFT LCD Panel

49 inch high brightness TFT LCD panel

49 inch high brightness TFT LCD panel is supplied for commercial display projects that need stable image quality, reliable structure, and practical after-sales support.

Best for: Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Screen size: 49 inch
Brightness: 500 nits, 800 cd/m2
Resolution: 1920 x 1080

Send screen size, application, destination country, and target delivery time for an accurate project quotation.

Configuration support
Pre-shipment inspection
Spare-parts planning

Technical Overview

Key Product Specifications

Screen Size	49 inch
Brightness	500 nits, 800 cd/m2
Resolution	1920 x 1080
Mounting / Structure	Wall, open-frame, floor-standing, or project-specific options
Control System	Matched to content, connectivity, and project requirements

How to read and verify these specifications

The information on this page is compiled from the available model content and project configuration data maintained by Shangxian Display. Values such as brightness, refresh rate, IP rating, cabinet structure, control system, warranty, and certificates can vary by model and project.

Confirm the final specification sheet and quotation before placing an order. Review our quality control process.

Selection Guide

Project Fit And Buying Inputs

Recommended Use

Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Confirm Before Selection

Confirm diagonal size, brightness, native resolution, operating hours, orientation, enclosure, mounting, and media connectivity.

Quotation Scope

Final specifications, packing, spare parts, lead time, warranty, and certificates are confirmed in the project quotation.

Read Full Product Description

What is a 49 inch High Brightness TFT LCD Panel?

A 49 inch high brightness TFT LCD (Thin-Film-Transistor Liquid Crystal Display) panel is an advanced display technology that utilizes high-quality liquid crystals and thin-film transistors to create clear, vibrant visuals. With its 49-inch size and high brightness capabilities, this TFT LCD panel has gained popularity among various applications, especially for outdoor installations or areas with intense ambient lights, where conventional displays struggle to maintain their visibility.

Features of the 49 inch High Brightness TFT LCD Panel

High Brightness: With a typical brightness level of around 1,500 nits to 2,500 nits, the 49 inch high brightness TFT LCD panel ensures excellent visibility even under direct sunlight or intense ambient lighting. This feature allows businesses to provide an optimal viewing experience in various settings without compromising on image quality. Wide Viewing Angle: This TFT LCD panel offers a wide viewing angle of 178° for both horizontal and vertical directions, ensuring precise and clear visuals in any position or orientation. Full HD Resolution: The 49 inch high brightness TFT LCD panel boasts a full HD resolution of 1920 x 1080 pixels, providing crisp and detailed imagery for multimedia-rich content. Energy Efficiency: The panel’s energy-saving technology consumes less power than conventional displays, reducing operational costs and benefiting the environment. Robust Construction: The panel is designed to be durable and reliable, making it ideal for use in demanding environments. It is built to resist impact, vibration, and extreme temperatures, ensuring longevity and consistent performance. Wide Color Gamut: This TFT LCD panel supports a wide color gamut, delivering lifelike and vibrant colors to create more engaging and immersive content. Easy Integration: The panel’s versatile interfaces, such as HDMI, VGA, and DVI, enable seamless integration with various hardware and software systems.

Application of the 49 inch High Brightness TFT LCD Panel

The versatility and robust features of the 49 inch high brightness TFT LCD panel make it suitable for diverse applications, including: Digital Signage: The panel’s high brightness and crisp visuals make it perfect for digital signage in shopping malls, airports, train stations, and other high-traffic areas. Outdoor Advertising: The panel’s visibility under direct sunlight and durability make it ideal for outdoor advertising in billboards, bus stops, and other public spaces. Information Kiosks: The 49 inch panel can be utilized in touchscreen kiosks for providing information and interactive services in tourist attractions, conference centers, and exhibitions. Surveillance & Security: The panel’s high resolution enables it to display high-quality video feeds from multiple security cameras, making it a suitable choice for control rooms of various industries. Hospitality Industry: Restaurants, hotels, and resorts can use the 49-inch high brightness TFT LCD panel to create interactive menus and digital displays for their lobbies.

49 inch high brightness TFT LCD panel Supplier

Technology Co.,Ltd. is a professional LED display and LCD display solution supplier.The 49 inch high brightness TFT LCD panel stands out as an exceptional display solution for various applications demanding high brightness, large size, and top-notch image quality. Its impressive features and diverse application opportunities make it a popular choice for businesses looking to invest in an efficient and visually appealing display solution.If you need a high-quality High Brightness LCD Panel to perfect your project, please contact us and we will provide you with a complete LCD display customization solution.

Screen Diagonal	49 inch
Brand	Confirmed per project
Model No	RS490EGY-NE08
Active Area	1073.78(W)×604(H) mm
Resolution	3840(3)×2160, UHD, 90PPI
Physical Size	1094(H）625.4(V)17.7(D)mm
Pixel Arrangement	R.G.B. Vertical Stripe
Display Mode	a-Si TFT-LCD, LCM
Contrast Ratio :	1100:1
White Luminance ( Center )	800 cd/m2 (Typ.) [cd/m2 ]
Optical Response Time	6 (Typ.)(G to G) ms
Nominal Input Voltage	12.0V (Typ.)
Frame Rate	60Hz
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Weight [kg]	7(Typ.)
Interface Type	V-by-One 8 lane , 51 pins
Support Color	1.07B , 63% NTSC
Surface Treatment	Antiglare (Haze 1%),Hard coating (3H)
RoHS Compliance	RoHS Compliance
Temperature Range	0 ~50 °C
Storage (Non-Operating)	-20 ~ 65 °C

Project Support

Support Before Production And Delivery

Configuration Review

Match the product to viewing distance, brightness, content, installation environment, maintenance access, and control requirements.

Factory Verification

Confirm the approved model, cabinet quantity, accessories, visual checks, and project-specific inspection requirements before shipment.

Delivery Preparation

Review packing, spare parts, shipping information, installation documents, warranty terms, and support contacts in the final quotation.

Applications

Typical Project Applications

Window-facing retail advertising
Outdoor information kiosks and digital signage
Transport and passenger-information displays
Open-frame and custom commercial installations

Project Quotation

Tell Us About Your Project

For a useful comparison, share the screen size, application, viewing distance, installation place, destination country, and target delivery date.

Recommended model and configuration
Commercial quotation and lead-time confirmation
Packing, spare-parts, and shipping planning

Email: info@sxleddisplay.com

WhatsApp: +86 15617669952

Buying Guide

Common Questions Before Quotation

How do I choose the right specification?

Share the screen size, viewing distance, indoor or outdoor environment, content type, and installation method. We can suggest pixel pitch, brightness, cabinet type, and control system options.

Can the product be customized?

Yes. Cabinet size, brightness, installation structure, maintenance direction, packaging, spare parts, and control system can be discussed according to the project.

What should I send for a quote?

Please send product model, screen width and height, usage location, target delivery time, and any drawing or project photo. Clear project details make the quotation faster and more accurate.
