High Brightness TFT LCD Panel

17 inch 700 nits high brightness TFT LCD panel

17 inch 700 nits high brightness TFT LCD panel is supplied for commercial display projects that need stable image quality, reliable structure, and practical after-sales support.

Best for: Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Screen size: 17 inch
Brightness: 700 nits, 700 cd/m2
Resolution: 1920x1080

Send screen size, application, destination country, and target delivery time for an accurate project quotation.

Configuration support
Pre-shipment inspection
Spare-parts planning

Technical Overview

Key Product Specifications

Screen Size	17 inch
Brightness	700 nits, 700 cd/m2
Resolution	1920x1080
Mounting / Structure	Wall, open-frame, floor-standing, or project-specific options
Control System	Matched to content, connectivity, and project requirements

How to read and verify these specifications

The information on this page is compiled from the available model content and project configuration data maintained by Shangxian Display. Values such as brightness, refresh rate, IP rating, cabinet structure, control system, warranty, and certificates can vary by model and project.

Confirm the final specification sheet and quotation before placing an order. Review our quality control process.

Selection Guide

Project Fit And Buying Inputs

Recommended Use

Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Confirm Before Selection

Confirm diagonal size, brightness, native resolution, operating hours, orientation, enclosure, mounting, and media connectivity.

Quotation Scope

Final specifications, packing, spare parts, lead time, warranty, and certificates are confirmed in the project quotation.

Read Full Product Description

What is a 17 inch 700 nits high brightness TFT LCD panel?

A 17 inch 700 nits high brightness TFT LCD panel is a cutting-edge, thin-film transistor (TFT) liquid crystal display (LCD) that offers exceptional image quality and performance. With a 17 inch screen size, it provides ample space for sharp and clear visuals, while the 700 nits brightness ensures the display remains visible even in direct sunlight or brightly lit environments.

Features of 17 inch 700 nits high brightness TFT LCD panel

High Brightness: With a brightness of 700 nits, this TFT LCD panel delivers exceptional clarity and visibility in various lighting conditions, including bright outdoor environments and well-lit indoor spaces. Wide Viewing Angle: The 17 inch TFT LCD panel features an ultra-wide viewing angle of 178°, ensuring clear and accurate color reproduction from any viewing position. High Resolution: The panel offers a high resolution (typically 1920×1080 or higher), resulting in crisp, detailed visuals perfect for multimedia applications, text, and images. LED Backlight Technology: Equipped with LED backlight technology, the panel provides improved contrast, energy efficiency, and a thinner design compared to traditional CCFL backlighting. Long Lifespan: With a robust build and advanced technology, the TFT LCD panel is designed for long-lasting performance, offering years of reliable use. Flexible Connectivity: The 17 inch TFT LCD panel comes with versatile connectivity options, usually including VGA, DVI, and HDMI, to ensure seamless integration with a range of devices and systems.

Application of 17 inch 700 nits high brightness TFT LCD panel

The 17 inch 700 nits high brightness TFT LCD panel is ideal for various applications such as: Outdoor Digital Signage: Due to its high brightness and wide viewing angle, the panel is perfect for outdoor advertising and digital signage applications, offering excellent visibility in any lighting condition. Industrial Control and Monitoring Systems: The panel’s high resolution, robust design, and flexible connectivity options make it suitable for use in industrial control and monitoring applications, providing precise visual data for efficient system management. Gaming and Multimedia: The TFT LCD panel’s stunning visuals and wide viewing angle are ideal for gaming, video or photo editing, and other multimedia applications, allowing for immersive and accurate color reproduction. Medical Imaging: The high resolution and contrast ratio make the panel suitable for applications that require accurate color representation and sharp visuals, such as medical imaging. Marine Navigation and Avionics Systems: With its high brightness, wide viewing angle, and long-lasting performance, the panel can be used effectively in marine navigation and avionics systems, ensuring optimal visibility in various conditions.

17 inch 700 nits high brightness TFT LCD panel Supplier

Technology Co.,Ltd. is a professional LED display and LCD display solution supplier.The 17 inch 700 nits high brightness TFT LCD panel is a versatile, high-quality display solution for a broad range of applications. With its impressive brightness, wide viewing angle, and advanced features, this panel delivers outstanding performance and exceptional visuals, making it ideal for various industries and environments.If you need a high-quality High Brightness LCD Panel to perfect your project, please contact us and we will provide you with a complete LCD display customization solution.

Screen Diagonal	17 inch
Model No	RS170ETN-NE07
Active Area	337.92(W)×270.336(H) mm
Pixels	1280(RGB)×1024,
Physical Size	358.5(W)×296.5(H)×10.8(D) mm
Pixel Arrangement	R.G.B. Vertical Stripe
Display Mode	a-Si TFT-LCD, LCM
White Luminance ( Center )	700 cd/m2 (Typ.) [cd/m2 ]
Contrast Ratio	1000:1 (Typ.)
Optical Response Time	8 (Typ.)(G to G) ms
Nominal Input Voltage	12V (Typ.)
Frame Rate	60Hz
Viewing Angle	85/85/80/80 (Typ.)(CR≥10)
Weight	1.27Kgs (Typ.)
Interface Type	LVDS (2 ch, 8-bit) , 30 pins Connector
Support Color	16.7M (6-bit + Hi-FRC)
RoHS Compliance	RoHS Compliance
Temperature Range	0 ~50 °C
Storage (Non-Operating)	-20 ~ 60 °C

Project Support

Support Before Production And Delivery

Configuration Review

Match the product to viewing distance, brightness, content, installation environment, maintenance access, and control requirements.

Factory Verification

Confirm the approved model, cabinet quantity, accessories, visual checks, and project-specific inspection requirements before shipment.

Delivery Preparation

Review packing, spare parts, shipping information, installation documents, warranty terms, and support contacts in the final quotation.

Applications

Typical Project Applications

Window-facing retail advertising
Outdoor information kiosks and digital signage
Transport and passenger-information displays
Open-frame and custom commercial installations

Project Quotation

Tell Us About Your Project

For a useful comparison, share the screen size, application, viewing distance, installation place, destination country, and target delivery date.

Recommended model and configuration
Commercial quotation and lead-time confirmation
Packing, spare-parts, and shipping planning

Email: info@sxleddisplay.com

WhatsApp: +86 15617669952

Buying Guide

Common Questions Before Quotation

How do I choose the right specification?

Share the screen size, viewing distance, indoor or outdoor environment, content type, and installation method. We can suggest pixel pitch, brightness, cabinet type, and control system options.

Can the product be customized?

Yes. Cabinet size, brightness, installation structure, maintenance direction, packaging, spare parts, and control system can be discussed according to the project.

What should I send for a quote?

Please send product model, screen width and height, usage location, target delivery time, and any drawing or project photo. Clear project details make the quotation faster and more accurate.
