High Brightness TFT LCD Panel

32 inch 4K high brightness TFT LCD panel

32 inch 4K high brightness TFT LCD panel is supplied for commercial display projects that need stable image quality, reliable structure, and practical after-sales support.

Best for: Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Screen size: 32 inch, 32 inches
Brightness: 1000 cd/m2
Resolution: 3840x2160

Send screen size, application, destination country, and target delivery time for an accurate project quotation.

Configuration support
Pre-shipment inspection
Spare-parts planning

Technical Overview

Key Product Specifications

Screen Size	32 inch, 32 inches
Brightness	1000 cd/m2
Resolution	3840x2160
Mounting / Structure	Wall, open-frame, floor-standing, or project-specific options
Control System	Matched to content, connectivity, and project requirements

How to read and verify these specifications

The information on this page is compiled from the available model content and project configuration data maintained by Shangxian Display. Values such as brightness, refresh rate, IP rating, cabinet structure, control system, warranty, and certificates can vary by model and project.

Confirm the final specification sheet and quotation before placing an order. Review our quality control process.

Selection Guide

Project Fit And Buying Inputs

Recommended Use

Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Confirm Before Selection

Confirm diagonal size, brightness, native resolution, operating hours, orientation, enclosure, mounting, and media connectivity.

Quotation Scope

Final specifications, packing, spare parts, lead time, warranty, and certificates are confirmed in the project quotation.

Read Full Product Description

What is 32 inch 4K High Brightness TFT LCD Panel?

A 32-inch 4K high brightness TFT (Thin-Film Transistor) LCD (Liquid Crystal Display) panel is a cutting-edge display technology that offers remarkable image quality, high resolution, and improved brightness. It measures 32 inches diagonally and offers 4K ultra-high definition (UHD) resolution, which equates to a stunning 3840×2160 pixels. This advanced TFT LCD panel uses thin-film transistor technology to control individual pixels, resulting in an unparalleled visual experience for users.

Features of 32-inch 4K High Brightness TFT LCD Panel

Superior 4K Resolution: With a 3840×2160 resolution, this panel displays sharper and more detailed images than standard high-definition displays. The substantial pixel density enables the panel to depict content with remarkable clarity and color accuracy. High-Brightness Display: Enhanced brightness levels make this panel perfect for use in various lighting situations, allowing viewers to enjoy stunning visuals even in well-lit environments. Wide Viewing Angles: The panel offers wide viewing angles, ensuring that viewers seated at different positions or angles can still enjoy the high-quality visuals without experiencing color shifts or distortion. Energy Efficiency: Using advanced technologies, such as a high-performance backlight system, the panel achieves a perfect balance between energy consumption and improved brightness, ensuring a more environmentally friendly experience. Versatility: The 32-inch 4K high brightness TFT LCD panel’s versatility allows it to be used in various sectors, including indoor and outdoor applications, and in demanding environments.

Application of 32-inch 4K High Brightness TFT LCD Panel

Digital Signage: With its high brightness and impressive resolution, this panel is perfect for retail stores, restaurants, and public spaces, offering an eye-catching and engaging visual experience for potential customers. Professional Monitors: The panel can be used in various professional scenarios, such as medical imaging, video editing, graphic design, and color-critical applications, where image quality and accuracy are crucial. Gaming: Gamers seeking an immersive experience will find enhanced 4K resolution and vibrant colors in this panel to be a perfect fit for high-performance gaming displays and setups. Outdoor Kiosks: Thanks to its high brightness capabilities, this panel is well-suited for outdoor kiosks, advertising, and other applications where direct sunlight or brightly lit surroundings are involved. Control Rooms: When monitoring and decision-making rely on accurate and clear visuals, this panel is an ideal choice for control centers, traffic management systems, and surveillance.

32 inch 4K high brightness TFT LCD panel Supplier

Technology Co.,Ltd. is a professional LED display and LCD display solution supplier.The 32-inch 4K high brightness TFT LCD panel is an outstanding and versatile display technology with numerous applications. Its combination of features offers an exceptional viewing experience, ensuring that it is an excellent choice for various industries and sectors.If you need a high-quality High Brightness LCD Panel to perfect your project, please contact us and we will provide you with a complete LCD display customization solution.

Screen Diagonal	31.5 inch
panel no	RS315DJJ-NE10
Brand	RisingLCD
Model No	RS315DJJ-NE10
Active Area	698.4(H)X 392.85(V)
Resolution	3840(RGB)×2160, UHD, 139PPI
Physical Size	731.1(W)×425.7(H)×32.9(D) mm
Pixel Arrangement	R.G.B. Vertical Stripe
Display Mode	a-Si TFT-LCD, LCM
Contrast Ratio :	3000:1
White Luminance ( Center )	1000 cd/m2 (Typ.) [cd/m2 ]
Optical Response Time	9.5 (Typ.)(G to G) ms
Nominal Input Voltage	12 V (Typ.)
Frame Rate	60Hz
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Weight [g]	6.6kgs
Interface Type	51 pins V-by-One 8 lane ,
Support Color	1.07B , 79% NTSC
Surface Treatment	Matte (Haze 25%) , Hard coating (3H)
RoHS Compliance	RoHS Compliance
Temperature Range	0 ~50 °C
Storage (Non-Operating)	-20 ~ 60 °C

Project Support

Support Before Production And Delivery

Configuration Review

Match the product to viewing distance, brightness, content, installation environment, maintenance access, and control requirements.

Factory Verification

Confirm the approved model, cabinet quantity, accessories, visual checks, and project-specific inspection requirements before shipment.

Delivery Preparation

Review packing, spare parts, shipping information, installation documents, warranty terms, and support contacts in the final quotation.

Applications

Typical Project Applications

Window-facing retail advertising
Outdoor information kiosks and digital signage
Transport and passenger-information displays
Open-frame and custom commercial installations

Project Quotation

Tell Us About Your Project

For a useful comparison, share the screen size, application, viewing distance, installation place, destination country, and target delivery date.

Recommended model and configuration
Commercial quotation and lead-time confirmation
Packing, spare-parts, and shipping planning

Email: info@sxleddisplay.com

WhatsApp: +86 15617669952

Buying Guide

Common Questions Before Quotation

How do I choose the right specification?

Share the screen size, viewing distance, indoor or outdoor environment, content type, and installation method. We can suggest pixel pitch, brightness, cabinet type, and control system options.

Can the product be customized?

Yes. Cabinet size, brightness, installation structure, maintenance direction, packaging, spare parts, and control system can be discussed according to the project.

What should I send for a quote?

Please send product model, screen width and height, usage location, target delivery time, and any drawing or project photo. Clear project details make the quotation faster and more accurate.
