High Brightness TFT LCD Panel
21.5 inch high brightness TFT LCD panel
21.5 inch high brightness TFT LCD panel is supplied for commercial display projects that need stable image quality, reliable structure, and practical after-sales support.
Best for: Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.
- Screen size
- 21.5 inch
- Brightness
- 1500 nits, 1000 cd/m2
- Resolution
- 1920x1080
Send screen size, application, destination country, and target delivery time for an accurate project quotation.
- Configuration support
- Pre-shipment inspection
- Spare-parts planning
Technical Overview
Key Product Specifications
| Screen Size | 21.5 inch |
|---|---|
| Brightness | 1500 nits, 1000 cd/m2 |
| Resolution | 1920x1080 |
| Mounting / Structure | Wall, open-frame, floor-standing, or project-specific options |
| Control System | Matched to content, connectivity, and project requirements |
How to read and verify these specifications
The information on this page is compiled from the available model content and project configuration data maintained by Shangxian Display. Values such as brightness, refresh rate, IP rating, cabinet structure, control system, warranty, and certificates can vary by model and project.
Confirm the final specification sheet and quotation before placing an order. Review our quality control process.
Selection Guide
Project Fit And Buying Inputs
Recommended Use
Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.
Confirm Before Selection
Confirm diagonal size, brightness, native resolution, operating hours, orientation, enclosure, mounting, and media connectivity.
Quotation Scope
Final specifications, packing, spare parts, lead time, warranty, and certificates are confirmed in the project quotation.
Read Full Product Description
What is 21.5 Inch High Brightness TFT LCD Panel?
A 21.5 inch high brightness TFT (Thin-Film Transistor) LCD (Liquid Crystal Display) panel is a modern, highly reliable, and technologically advanced display panel that is specifically designed for environments with high ambient light levels. This type of display provides an enhanced visual experience, allowing for superior readability, extended reliability, and optimum viewability in both indoor and outdoor applications.
Features of 21.5 Inch High Brightness TFT LCD Panel
High Brightness This 21.5 inch TFT LCD panel boasts a high brightness level, usually in the range of 1000 to 1500 nits, ensuring optimal performance under strong sunlight or other high ambient light conditions. High brightness capability reduces the negative effects of sun glare and enhances both the readability and visibility of the screen’s content. Wide Viewing Angle The display panel provides an impressive wide viewing angle, enabling users to experience outstanding visibility from various directions. This feature ensures that images and information retain their quality and color accuracy even when viewed from angles as wide as 178 degrees both horizontally and vertically. Energy-Efficient Design One of the most vital features of this 21.5 inch high brightness TFT LCD panel is its energy efficiency. The advanced technology embedded in the panel ensures that energy consumption is minimized, providing a green solution for long-term operation and reduced overall cost of ownership. Enhanced Lifespan The high brightness TFT LCD panel is designed for extended use and durability. These panels are manufactured using high-quality components and adhere to strict production standards to ensure that the display maintains optimal performance even after long operating hours. High Resolution and Contrast The 21.5 inch high brightness TFT LCD panel offers full HD resolution (1920×1080), providing crisp and clear images. Combined with a high contrast ratio, this feature guarantees detailed images, sharp text, and vibrant colors. Robust and Weather-Resistant Design The display panel’s design allows it to withstand demanding environments. Featuring a rugged, water-resistant, and dustproof enclosure, the panel ensures long-term reliability and performance under various challenging conditions.
Application of 21.5 Inch High Brightness TFT LCD Panel
The 21.5 inch high brightness TFT LCD panel has diverse applications in industries where superior quality outdoor and indoor visibility is essential. Some of the most common applications include: Outdoor Digital Signage: Ideal for outdoor promotions, advertising, wayfinding, and public announcements where visibility and reliability are critical. Transportation: Utilized in airports, train stations, and bus stops for displaying travel schedules, advertising, and other important information. Retail and Hospitality: Suitable for showcasing promotional materials, digital menus, and interactive displays within stores, restaurants, or hotels. Healthcare: Used in hospitals and clinics to display patient information, appointment schedules, or promotional content. Industrial: Employed in control rooms, automation systems, and manufacturing facilities to closely monitor processes and enhance operational efficiency.
21.5 inch high brightness TFT LCD panel Supplier
Technology Co.,Ltd. is a professional LED display and LCD display solution supplier.The 21.5 inch high brightness TFT LCD panel offers an impressive range of features and applications, making it a superior choice for any industry looking to enhance the visibility and durability of their display systems.If you need a high-quality High Brightness LCD Panel to perfect your project, please contact us and we will provide you with a complete LCD display customization solution.
| Screen Diagonal | 21.5 inch |
| Brand | Confirmed per project |
| Model No | RS215HVN-NE10 |
| Active Area | 476.64(W)×268.11(H) mm |
| Resolution | 1920(RGB)×1080, FHD, 102PPI |
| Physical Size | 495.6(W)×292.2(H)×11(D) mm |
| Pixel Arrangement | R.G.B. Vertical Stripe |
| Display Mode | a-Si TFT-LCD, LCM |
| Contrast Ratio : | 3000:1 |
| White Luminance ( Center ) | 1000 cd/m2 (Typ.) [cd/m2 ] |
| Optical Response Time | 13/5 (Typ.)(Tr/Td) ms |
| Nominal Input Voltage | 5.0V (Typ.) |
| Frame Rate | 60Hz |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Weight [kg] | 1.67kgs |
| Interface Type | 30 pins LVDS (2 ch, 8-bit) |
| Support Color | 16.7M , 72% sRGB |
| Surface Treatment | Matte, Hard coating (3H) |
| RoHS Compliance | RoHS Compliance |
| Temperature Range | 0 ~50 °C |
| Storage (Non-Operating) | -20 ~ 60 °C |
Project Support
Support Before Production And Delivery
Configuration Review
Match the product to viewing distance, brightness, content, installation environment, maintenance access, and control requirements.
Factory Verification
Confirm the approved model, cabinet quantity, accessories, visual checks, and project-specific inspection requirements before shipment.
Delivery Preparation
Review packing, spare parts, shipping information, installation documents, warranty terms, and support contacts in the final quotation.
Applications
Typical Project Applications
- Window-facing retail advertising
- Outdoor information kiosks and digital signage
- Transport and passenger-information displays
- Open-frame and custom commercial installations

Project Quotation
Tell Us About Your Project
For a useful comparison, share the screen size, application, viewing distance, installation place, destination country, and target delivery date.
- Recommended model and configuration
- Commercial quotation and lead-time confirmation
- Packing, spare-parts, and shipping planning
Email: info@sxleddisplay.com
WhatsApp: +86 15617669952
Buying Guide
Common Questions Before Quotation
How do I choose the right specification?
Share the screen size, viewing distance, indoor or outdoor environment, content type, and installation method. We can suggest pixel pitch, brightness, cabinet type, and control system options.
Can the product be customized?
Yes. Cabinet size, brightness, installation structure, maintenance direction, packaging, spare parts, and control system can be discussed according to the project.
What should I send for a quote?
Please send product model, screen width and height, usage location, target delivery time, and any drawing or project photo. Clear project details make the quotation faster and more accurate.
