High Brightness TFT LCD Panel

19.5 Inch 1500 Nits High Brightness Strip LCD Panel

19.5 Inch 1500 Nits High Brightness Strip LCD Panel is supplied for commercial display projects that need stable image quality, reliable structure, and practical after-sales support.

Best for: Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Screen size: 19.5 Inch
Brightness: 1500 Nits, 1500 cd/m2
Resolution: 1920x1080

Send screen size, application, destination country, and target delivery time for an accurate project quotation.

Configuration support
Pre-shipment inspection
Spare-parts planning

Technical Overview

Key Product Specifications

Screen Size	19.5 Inch
Brightness	1500 Nits, 1500 cd/m2
Resolution	1920x1080
Mounting / Structure	Wall, open-frame, floor-standing, or project-specific options
Control System	Matched to content, connectivity, and project requirements

How to read and verify these specifications

The information on this page is compiled from the available model content and project configuration data maintained by Shangxian Display. Values such as brightness, refresh rate, IP rating, cabinet structure, control system, warranty, and certificates can vary by model and project.

Confirm the final specification sheet and quotation before placing an order. Review our quality control process.

Selection Guide

Project Fit And Buying Inputs

Recommended Use

Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Confirm Before Selection

Confirm diagonal size, brightness, native resolution, operating hours, orientation, enclosure, mounting, and media connectivity.

Quotation Scope

Final specifications, packing, spare parts, lead time, warranty, and certificates are confirmed in the project quotation.

Read Full Product Description

What is 19.5 Inch 1500 Nits High Brightness Strip LCD Panel?

The 19.5 Inch 1500 Nits High Brightness Strip LCD Panel is a top-of-the-line, cutting-edge display technology product that delivers unparalleled performance in terms of brightness, efficiency, and versatility. This slim and sleek panel features 1500 nits of brightness, making it perfect for use in a wide range of applications, including retail signage, advertising displays, and industrial environments where high visibility is crucial.

Features of 19.5 Inch 1500 Nits High Brightness Strip LCD Panel

Exceptional Brightness: Offering 1500 nits of brightness, thisStrip LCD panel ensures high visibility even in brightly lit environments, providing a crystal-clear display with vibrant colors. Wide Viewing Angle: The panel features a wide viewing angle which means your content can be viewed from all directions with minimal color and contrast distortion. High Resolution: With a native resolution of 1920×1080 pixels, the 19.5-inch panel provides sharp, lifelike images, enhancing the visual experience for viewers. Industrial Grade: The High Brightness Strip LCD Panel is built to withstand the rigors of demanding industrial environments, ensuring longevity and reliability in tough conditions. Versatile Connectivity: The panel comes equipped with multiple input options, such as HDMI and VGA, for easily connecting to a wide variety of video sources. Energy Efficient: The innovative LED backlighting technology used in this panel consumes less power than traditional CCFL backlighting, resulting in lower energy costs and a reduced carbon footprint. Easy Integration: The slim and compact design of the 19.5-inch High Brightness Strip LCD Panel makes it easy to integrate into various enclosure types and mounting configurations.

Application of 19.5 Inch 1500 Nits High Brightness Strip LCD Panel

The remarkable features of this High Brightness Strip LCD Panel make it suitable for a diverse range of applications, including: Retail Signage: The panel’s high brightness ensures that promotions, product information, and marketing materials are highly visible, helping to attract more customers and boost sales. Transportation: In airports, train stations, and bus terminals, the High Brightness Strip LCD Panel provides clear, easily readable displays for essential information like schedules, routes, and delays. Industrial Automation: With its high brightness and industrial-grade build quality, the Strip LCD Panel is ideal for displaying essential system information, making it easier for operators to monitor and control various processes. Outdoor Advertising: When installed within weatherproof enclosures, the High Brightness Strip LCD Panel is perfect for outdoor advertising applications, generating striking visuals that grab attention. Public Information: Government agencies and other organizations can use the panel to provide an efficient and high-quality platform for displaying public information, notifications, or emergency alerts.

19.5 Inch 1500 Nits High Brightness Strip LCD Panel Supplier

Technology Co.,Ltd. is a professional LED display and LCD display solution supplier.The 19.5 Inch 1500 Nits High Brightness Strip LCD Panel delivers a remarkable combination of brightness, resolution, and durability that is suitable for a wide range of applications. Its outstanding features can help enhance the visibility and impact of your content, ensuring that your message always stands out.If you need a high-quality High Brightness LCD Panel to perfect your project, please contact us and we will provide you with a complete LCD display customization solution.

Screen Diagonal	19.5 inch
Model No	RS195HAN-GE15
Active Area	478.64(W)×136.41(H) mm
Pixels	1920(RGB)×540,
Physical Size	497.4(W)×158.4(H)×15.7(D) mm
Pixel Arrangement	R.G.B. Vertical Stripe
Display Mode	a-Si TFT-LCD, LCM
White Luminance ( Center )	1500 cd/m2 (Typ.) [cd/m2 ]
Contrast Ratio	3000:1 (Typ.)
Optical Response Time	8 (Typ.)(G to G) ms
Nominal Input Voltage	6V (Typ.)
Frame Rate	60Hz
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Weight	N/A
Interface Type	LVDS (2 ch, 8-bit) , 30 pins Connector
Support Color	1.07B
RoHS Compliance	RoHS Compliance
Temperature Range	-30 ~80 °C
Storage (Non-Operating)	-40 ~ 90 °C

Project Support

Support Before Production And Delivery

Configuration Review

Match the product to viewing distance, brightness, content, installation environment, maintenance access, and control requirements.

Factory Verification

Confirm the approved model, cabinet quantity, accessories, visual checks, and project-specific inspection requirements before shipment.

Delivery Preparation

Review packing, spare parts, shipping information, installation documents, warranty terms, and support contacts in the final quotation.

Applications

Typical Project Applications

Window-facing retail advertising
Outdoor information kiosks and digital signage
Transport and passenger-information displays
Open-frame and custom commercial installations

Project Quotation

Tell Us About Your Project

For a useful comparison, share the screen size, application, viewing distance, installation place, destination country, and target delivery date.

Recommended model and configuration
Commercial quotation and lead-time confirmation
Packing, spare-parts, and shipping planning

Email: info@sxleddisplay.com

WhatsApp: +86 15617669952

Buying Guide

Common Questions Before Quotation

How do I choose the right specification?

Share the screen size, viewing distance, indoor or outdoor environment, content type, and installation method. We can suggest pixel pitch, brightness, cabinet type, and control system options.

Can the product be customized?

Yes. Cabinet size, brightness, installation structure, maintenance direction, packaging, spare parts, and control system can be discussed according to the project.

What should I send for a quote?

Please send product model, screen width and height, usage location, target delivery time, and any drawing or project photo. Clear project details make the quotation faster and more accurate.
