High Brightness TFT LCD Panel

17.3 inch high brightness TFT LCD panel

17.3 inch high brightness TFT LCD panel is supplied for commercial display projects that need stable image quality, reliable structure, and practical after-sales support.

Best for: Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Screen size: 17.3 inch
Brightness: 1000 nits, 1500 cd/m2
Resolution: 1920x1080

Send screen size, application, destination country, and target delivery time for an accurate project quotation.

Configuration support
Pre-shipment inspection
Spare-parts planning

Technical Overview

Key Product Specifications

Screen Size	17.3 inch
Brightness	1000 nits, 1500 cd/m2
Resolution	1920x1080
Mounting / Structure	Wall, open-frame, floor-standing, or project-specific options
Control System	Matched to content, connectivity, and project requirements

How to read and verify these specifications

The information on this page is compiled from the available model content and project configuration data maintained by Shangxian Display. Values such as brightness, refresh rate, IP rating, cabinet structure, control system, warranty, and certificates can vary by model and project.

Confirm the final specification sheet and quotation before placing an order. Review our quality control process.

Selection Guide

Project Fit And Buying Inputs

Recommended Use

Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.

Confirm Before Selection

Confirm diagonal size, brightness, native resolution, operating hours, orientation, enclosure, mounting, and media connectivity.

Quotation Scope

Final specifications, packing, spare parts, lead time, warranty, and certificates are confirmed in the project quotation.

Read Full Product Description

What is a 17.3-inch High Brightness TFT LCD Panel?

A 17.3-inch high brightness TFT LCD panel is a type of advanced display technology, featuring a 17.3-inch screen size with enhanced brightness capabilities. TFT (Thin-Film Transistor) technology enables improved color reproduction, while LCD (Liquid Crystal Display) utilizes liquid crystal solutions between two layers of glass or transparent material to display images. This merge of TFT and LCD technology enables the panel to deliver stunning visuals and vibrant colors while providing a high level of brightness, ideal for outdoor and indoor use.

Features of 17.3-inch High Brightness TFT LCD Panel

High Brightness: This panel features high brightness levels in the range of 800-1000 nits, providing clear, vibrant visuals in outdoor environments or under strong light conditions. Wide Viewing Angle: The 17.3-inch TFT LCD panel offers wide viewing angles up to 178°, ensuring crisp and accurate images, even when viewed from sharp angles. Full High Definition Resolution: The panel boasts a Full HD resolution (1920×1080 pixels) for sharp, detailed visuals, suitable for applications that demand high-quality content and accurate color reproduction. Slim Design: Due to advancements in technology, the overall thickness of these panels has been reduced, allowing a slim, lightweight design that saves space and is easy to integrate into various devices. Power Efficiency: The high brightness TFT LCD panel uses relatively low power to maintain high brightness levels, ensuring energy efficiency and cost savings on electricity consumption. Wide Color Gamut: The wide color gamut feature in these panels offers an array of colors, enhancing the overall visual experience, and providing more vibrant and lifelike images. Fast Response Time: With a fast response time, this panel is ideal for fast-paced applications, reducing ghosting and motion blur in videos and animations. Durability: The 17.3-inch high brightness TFT LCD panel is designed to withstand harsh conditions, making it suitable for various indoor and outdoor applications.

Application of 17.3-inch High Brightness TFT LCD Panel

Outdoor Digital Signage: The high brightness level makes this panel perfect for outdoor applications such as advertising, announcements, and public information displays, where readability in sunlight is crucial. Kiosks: Interactive kiosks, such as information or ticketing terminals, airport check-in counters, and self-service stations, benefit from the panel’s high-quality visuals and high brightness. Medical Equipment: The needs of medical professionals are met with the high resolution, wide color gamut, and enhanced brightness features, making these panels ideal for precise imaging in various medical devices. CCTV Monitors: With its fast response time, high resolution, and high brightness, this panel is suitable for CCTV monitors to ensure clear and bright video surveillance in security applications. Industrial Equipment: The durability and power efficiency of the 17.3-inch high brightness TFT LCD panel make it an excellent choice for industrial equipment and manufacturing control systems where reliable performance is required. Gaming: This panel is perfect for gaming on laptops and all-in-one computers, providing a seamless experience with rich, lifelike visuals and wide viewing angles. Professional Displays: The high quality, accuracy, and resolution of these panels make them suitable for professional displays used in graphic design, video editing, and photography.

17.3 inch high brightness TFT LCD panel Supplier

Technology Co.,Ltd. is a professional LED display and LCD display solution supplier.The 17.3-inch high brightness TFT LCD panel offers high-quality visuals, power efficiency, and a versatile range of applications, making it an excellent choice for both professional and consumer markets.If you need a high-quality High Brightness LCD Panel to perfect your project, please contact us and we will provide you with a complete LCD display customization solution.

Screen Diagonal	17.3 inch
Brand	Confirmed per project
Model No	RS173HW01-NE15
Active Area	381.888(W)×214.812(H) mm
Resolution	1920(RGB)×1080, FHD 127PPI
Physical Size	403(H)×240(V) ×13(D) mm
Pixel Arrangement	R.G.B. Vertical Stripe
Display Mode	a-Si TFT-LCD, LCM
Contrast Ratio :	600:1
White Luminance ( Center )	1500 cd/m2 (Typ.) [cd/m2 ]
Optical Response Time	8 (Typ.)(G to G) ms
Nominal Input Voltage	3.3V (Typ.)
Frame Rate	60Hz
Viewing Angle	80/80/60/80 (Typ.)(CR≥10)
Weight [kg]	1.1(Typ.)
Interface Type	30 pins LVDS (2 ch, 8-bit) ,
Support Color	16.7M ,
Surface Treatment	Glare , Hard coating (3H)
RoHS Compliance	RoHS Compliance
Temperature Range	0 ~70 °C
Storage (Non-Operating)	-20 ~ 70 °C

Project Support

Support Before Production And Delivery

Configuration Review

Match the product to viewing distance, brightness, content, installation environment, maintenance access, and control requirements.

Factory Verification

Confirm the approved model, cabinet quantity, accessories, visual checks, and project-specific inspection requirements before shipment.

Delivery Preparation

Review packing, spare parts, shipping information, installation documents, warranty terms, and support contacts in the final quotation.

Applications

Typical Project Applications

Window-facing retail advertising
Outdoor information kiosks and digital signage
Transport and passenger-information displays
Open-frame and custom commercial installations

Project Quotation

Tell Us About Your Project

For a useful comparison, share the screen size, application, viewing distance, installation place, destination country, and target delivery date.

Recommended model and configuration
Commercial quotation and lead-time confirmation
Packing, spare-parts, and shipping planning

Email: info@sxleddisplay.com

WhatsApp: +86 15617669952

Buying Guide

Common Questions Before Quotation

How do I choose the right specification?

Share the screen size, viewing distance, indoor or outdoor environment, content type, and installation method. We can suggest pixel pitch, brightness, cabinet type, and control system options.

Can the product be customized?

Yes. Cabinet size, brightness, installation structure, maintenance direction, packaging, spare parts, and control system can be discussed according to the project.

What should I send for a quote?

Please send product model, screen width and height, usage location, target delivery time, and any drawing or project photo. Clear project details make the quotation faster and more accurate.
