High Brightness Open Frame Monitor
55 inch high brightness open frame TFT LCD monitor
55 inch high brightness open frame TFT LCD monitor is supplied for commercial display projects that need stable image quality, reliable structure, and practical after-sales support.
Best for: Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.
- Screen size
- 55 inch
- Brightness
- 4000 nits, 3600 nits
- Application
- Commercial LCD
Send screen size, application, destination country, and target delivery time for an accurate project quotation.
- Configuration support
- Pre-shipment inspection
- Spare-parts planning
Technical Overview
Key Product Specifications
| Screen Size | 55 inch |
|---|---|
| Brightness | 4000 nits, 3600 nits |
| Resolution | Confirm native resolution by size and model |
| Mounting / Structure | Wall, open-frame, floor-standing, or project-specific options |
| Control System | Matched to content, connectivity, and project requirements |
How to read and verify these specifications
The information on this page is compiled from the available model content and project configuration data maintained by Shangxian Display. Values such as brightness, refresh rate, IP rating, cabinet structure, control system, warranty, and certificates can vary by model and project.
Confirm the final specification sheet and quotation before placing an order. Review our quality control process.
Selection Guide
Project Fit And Buying Inputs
Recommended Use
Retail, transport, hospitality, and information projects that need a high-resolution commercial LCD format.
Confirm Before Selection
Confirm diagonal size, brightness, native resolution, operating hours, orientation, enclosure, mounting, and media connectivity.
Quotation Scope
Final specifications, packing, spare parts, lead time, warranty, and certificates are confirmed in the project quotation.
Read Full Product Description
What is a 55-inch High Brightness Open Frame TFT LCD Monitor?
A 55-inch High Brightness Open Frame TFT LCD Monitor is an advanced display technology that provides a large and vibrant display solution. It combines TFT (Thin Film Transistor) and LCD (Liquid Crystal Display) technologies to offer superior image quality, high brightness levels, and rich colors that have a lasting visual impact. Featuring an open frame design, this monitor is adaptable and versatile, making it a perfect choice for various applications and installations.
Features of the 55-inch High Brightness Open Frame TFT LCD Monitor
High Brightness Equipped with a high brightness backlight, this 55-inch monitor boasts an impressive output, ensuring clear visibility even in sunny or brightly lit environments. The exceptional brightness makes it ideal for use in both indoor and outdoor applications. Open Frame Design The open frame design offers flexibility in assembly and integration, making this monitor highly versatile and suitable for a wide range of applications. Its sleek and minimalistic structure allows easy customization, fitting seamlessly into any setting. Wide Viewing Angle This TFT LCD monitor offers a wide viewing angle, enabling viewers to enjoy a consistent image quality from all angles. This feature is vital in providing excellent visibility to a large audience or in situations where the display angles cannot be pre-determined. Exceptional Color Quality and Contrast With an impressive color gamut and exceptional contrast ratio, this 55-inch monitor is capable of producing vivid and realistic images. It accurately reproduces colors, ensuring precise and vibrant visuals across various applications. Energy-efficient and Environmentally friendly Designed to save energy and minimize environmental impact, the 55-inch High Brightness Open Frame TFT LCD Monitor supports sustainable practices. It offers excellent energy efficiency and an extended operational life, cutting down on maintenance costs and ensuring impressive performance. Multiple Interface Options The monitor is compatible with various connectivity options, making it an adaptable device. It supports HDMI, VGA, DVI, and other standard interfaces, allowing seamless integration with a broad range of devices and systems.
Application of the 55-inch High Brightness Open Frame TFT LCD Monitor
The 55-inch High Brightness Open Frame TFT LCD Monitor caters to a wide range of professional and commercial applications, including: Digital Signage: Outdoor or indoor digital signage and advertising displays, providing clear visibility even in bright environments. Retail: Showcasing merchandise and promotional content in stores, supermarkets, and shopping centers. Transportation: Displaying real-time transit information and schedules at airports, railway stations, and bus terminals. Entertainment: Multiplexes, casinos, and theme parks, where large, dynamic screens captivate the audience. Control Rooms: Critical environments like traffic control centers, security monitoring stations, and network operation centers. Healthcare: Enhancing patient care through medical display screens and assisting in telemedicine constellations. Industrial applications: As human-machine interface (HMI) displays for monitoring and controlling industrial equipment and machinery.
55 inch high brightness open frame TFT LCD monitor Supplier
Technology Co.,Ltd. is a professional LED display and LCD display solution supplier.The 55-inch High Brightness Open Frame TFT LCD Monitor is a versatile and reliable display solution designed to meet a vast array of applications. Its high brightness levels, stellar image quality, and adaptable design make it a go-to choice for professionals and industries alike.If you need a high-quality High Brightness LCD Panel to perfect your project, please contact us and we will provide you with a complete LCD display customization solution.
| Panel | Screen Size | 46inch | 55inch | 65inch |
| Resolution | 1920*1080 FHD | 1920*1080 FHD | 3840*2160 UHD | |
| Brightness (nits) | 4000 nits (Typ.) 3600 nits(Min.) | 4000 nits (Typ.) 3600 nits(Min.) | 4000 nits (Typ.) 3600 nits(Min.) | |
| Display Area(mm) | 1018.08(W) X 572.67(H) mm | 1209.6(W) X 680.4(H) mm | 1428.28(W) X 803.52(H) mm | |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | 89/89/89/89 (Min.)(CR≥10) | 89/89/89/89 (Min.)(CR≥10) | |
| Color | 1.07B | 1.07B | 1.07B | |
| View angle (H x V) | 178/178 | 178/178 | 178/178 | |
| Ratio | 16:9 | 16:9 | 16:9 | |
| Contrast Ratio | 4000:1 | 1100:1 | 1200:1 | |
| Portrait/Landscape | Yes/Yes | Yes/Yes | Yes/Yes | |
| Product Specification | Products Size (H*V*D)(mm) | 1050.6(H) *610.3(V) * 78.7(D) | 1242.1(H) *718(V) * 83(D) | 1461(H) *843.1(V) * 87(D) |
| Brightness Control | Auto-Sensitivity | Auto-Sensitivity | Auto-Sensitivity | |
| Power Supply | AC 110V/240V | AC 110V/240V | AC 110V/240V | |
| 50Hz/60Hz | 50Hz/60Hz | 50Hz/60Hz | ||
| Cooling System | Smart Direct Ventilation | Smart Direct Ventilation | Smart Direct Ventilation | |
| Power Consumption | 400W (Typ.) | 300W (Typ.) | 875W (Typ.) | |
| Operation Temperature | -20℃ to 70℃ | -20℃ to 70℃ | -20℃ to 70℃ | |
| Operation Humidity | 5%-90%RH | 5%-90%RH | 5%-90%RH | |
| VESA standard mount interface | 400 * 400mm | 400 * 400mm | 400 * 400mm | |
| Gross Weight | TBD | TBD | TBD | |
| Cooling Fan | NO | NO | NO | |
| Connectivity | Input | HDMI, DVI, VGA, PC, AUDIO | HDMI, DVI, VGA, PC, AUDIO | HDMI, DVI, VGA, PC, AUDIO |
| Output | Earphone | Earphone | Earphone |
Project Support
Support Before Production And Delivery
Configuration Review
Match the product to viewing distance, brightness, content, installation environment, maintenance access, and control requirements.
Factory Verification
Confirm the approved model, cabinet quantity, accessories, visual checks, and project-specific inspection requirements before shipment.
Delivery Preparation
Review packing, spare parts, shipping information, installation documents, warranty terms, and support contacts in the final quotation.
Applications
Typical Project Applications
- Window-facing retail advertising
- Outdoor information kiosks and digital signage
- Transport and passenger-information displays
- Open-frame and custom commercial installations

Project Quotation
Tell Us About Your Project
For a useful comparison, share the screen size, application, viewing distance, installation place, destination country, and target delivery date.
- Recommended model and configuration
- Commercial quotation and lead-time confirmation
- Packing, spare-parts, and shipping planning
Email: info@sxleddisplay.com
WhatsApp: +86 15617669952
Buying Guide
Common Questions Before Quotation
How do I choose the right specification?
Share the screen size, viewing distance, indoor or outdoor environment, content type, and installation method. We can suggest pixel pitch, brightness, cabinet type, and control system options.
Can the product be customized?
Yes. Cabinet size, brightness, installation structure, maintenance direction, packaging, spare parts, and control system can be discussed according to the project.
What should I send for a quote?
Please send product model, screen width and height, usage location, target delivery time, and any drawing or project photo. Clear project details make the quotation faster and more accurate.
